NTHD5903T1 Images
- Manufacturer: onsemi (ON)
- Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Arrays Package/Case: 8-SMD, Flat Lead
- Description: P-CHANNEL MOSFET
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
NTHD5903T1 Specifications:
- MfrPart.: NTHD5903T1
- Mfr: onsemi
- Description: P-CHANNEL MOSFET
- Product Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Arrays
- Package: Bulk
- Series: ChipFET™
- PartStatus: Obsolete
- FETType: 2 P-Channel (Dual)
- FETFeature: Logic Level Gate
- DraintoSourceVoltage(Vdss): 20V
- Current-ContinuousDrain(Id)@25°C: 2.2A (Ta)
- RdsOn(Max)@IdVgs: 155mOhm @ 2.2A, 4.5V
- Vgs(th)(Max)@Id: 600mV @ 250µA
- GateCharge(Qg)(Max)@Vgs: 7.4nC @ 4.5V
- InputCapacitance(Ciss)(Max)@Vds: -
- Power-Max: 1.1W (Ta)
- OperatingTemperature: -55°C ~ 150°C (TJ)
- MountingType: Surface Mount
- Package/Case: 8-SMD, Flat Lead
- NTHD5903T1 onsemi (ON), P-CHANNEL MOSFET, Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Arrays
NTHD5903T1, onsemi authentic parts in stock from onsemi (ON) authorized distributors, order today, can ship immediately.
