FGH40T65SQD_F155 Images
- Manufacturer: onsemi (ON)
- Category: Discrete Semiconductor Products~Transistors - IGBTs - Single Package/Case: TO-247-3
- Description: 650V FS4 TRENCH IGBT
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
FGH40T65SQD_F155 Specifications:
- MfrPart.: FGH40T65SQD_F155
- Mfr: onsemi
- Description: 650V FS4 TRENCH IGBT
- Product Category: Discrete Semiconductor Products~Transistors - IGBTs - Single
- Package: Tube
- Series: -
- PartStatus: Active
- IGBTType: Trench Field Stop
- Voltage-CollectorEmitterBreakdown(Max): 650 V
- Current-Collector(Ic)(Max): 80 A
- Current-CollectorPulsed(Icm): 160 A
- Vce(on)(Max)@VgeIc: 2.1V @ 15V, 40A
- Power-Max: 238 W
- SwitchingEnergy: 138µJ (on), 52µJ (off)
- InputType: Standard
- GateCharge: 80 nC
- Td(on/off)@25°C: 16.4ns/86.4ns
- TestCondition: 400V, 10A, 6Ohm, 15V
- ReverseRecoveryTime(trr): 31.8 ns
- OperatingTemperature: -55°C ~ 175°C (TJ)
- MountingType: Through Hole
- Package/Case: TO-247-3
- FGH40T65SQD_F155 onsemi (ON), 650V FS4 TRENCH IGBT, Discrete Semiconductor Products~Transistors - IGBTs - Single
FGH40T65SQD_F155, onsemi authentic parts in stock from onsemi (ON) authorized distributors, order today, can ship immediately.
