74AC20SJX onsemi IC GATE NAND 2CH 4-INP 14SOP
74AC20SJX Images
74AC20SJX Images
74AC20SJX
  • Manufacturer: onsemi (ON)
  • Category: Integrated Circuits (ICs)~Logic - Gates and Inverters SupplierDevicePackage: 14-SOP
  • Description: IC GATE NAND 2CH 4-INP 14SOP
  • COMPETITIVE PRICE and DELIVERY TIME
  • Order with confidence, there are no lead times for in-stock products.
Quickly Quote for You to Meet Your Target Price, Support Small Order Quantity with Fast Quick Delivery.
Download Datasheet (PDF)
74AC20SJX Datasheet
ELECTRONIC COMPONENTS, CHOOSE NHE ELECTRONICS
74AC20SJX Specifications:
  • MfrPart.: 74AC20SJX
  • Mfr: Fairchild Semiconductor (Now part of ONsemi)
  • Description: IC GATE NAND 2CH 4-INP 14SOP
  • Product Category: Integrated Circuits (ICs)~Logic - Gates and Inverters
  • Package: Bulk
  • Series: 74AC
  • PartStatus: Obsolete
  • LogicType: NAND Gate
  • NumberofCircuits: 2
  • NumberofInputs: 4
  • Features: -
  • Voltage-Supply: 2V ~ 6V
  • Current-Quiescent(Max): 2 µA
  • Current-OutputHighLow: 24mA, 24mA
  • LogicLevel-Low: 0.9V ~ 1.65V
  • LogicLevel-High: 2.1V ~ 3.85V
  • MaxPropagationDelay@VMaxCL: 7ns @ 5V, 50pF
  • OperatingTemperature: -40°C ~ 85°C
  • MountingType: Surface Mount
  • SupplierDevicePackage: 14-SOP
  • 74AC20SJX onsemi (ON), IC GATE NAND 2CH 4-INP 14SOP, Integrated Circuits (ICs)~Logic - Gates and Inverters
