SGS5N150UFTU Images
- Manufacturer: onsemi (ON)
- Category: Discrete Semiconductor Products~Transistors - IGBTs - Single Package/Case: TO-220-3 Full Pack
- Description: IGBT 1500V 10A 50W TO220F
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
SGS5N150UFTU Specifications:
- MfrPart.: SGS5N150UFTU
- Mfr: onsemi
- Description: IGBT 1500V 10A 50W TO220F
- Product Category: Discrete Semiconductor Products~Transistors - IGBTs - Single
- Package: Tube
- Series: -
- PartStatus: Obsolete
- IGBTType: -
- Voltage-CollectorEmitterBreakdown(Max): 1500 V
- Current-Collector(Ic)(Max): 10 A
- Current-CollectorPulsed(Icm): 20 A
- Vce(on)(Max)@VgeIc: 5.5V @ 10V, 5A
- Power-Max: 50 W
- SwitchingEnergy: 190µJ (on), 100µJ (off)
- InputType: Standard
- GateCharge: 30 nC
- Td(on/off)@25°C: 10ns/30ns
- TestCondition: 600V, 5A, 10Ohm, 10V
- ReverseRecoveryTime(trr): -
- OperatingTemperature: -55°C ~ 150°C (TJ)
- MountingType: Through Hole
- Package/Case: TO-220-3 Full Pack
- SGS5N150UFTU onsemi (ON), IGBT 1500V 10A 50W TO220F, Discrete Semiconductor Products~Transistors - IGBTs - Single
SGS5N150UFTU, onsemi authentic parts in stock from onsemi (ON) authorized distributors, order today, can ship immediately.
