NCP1294EDBR2G Images
- Manufacturer: onsemi (ON)
- Category: Integrated Circuits (ICs)~PMIC - AC DC Converters, Offline Switchers Package/Case: 16-TSSOP (0.173, 4.40mm Width)
- Description: IC OFFLINE SW MULT TOP 16TSSOP
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
NCP1294EDBR2G Specifications:
- MfrPart.: NCP1294EDBR2G
- Mfr: onsemi
- Description: IC OFFLINE SW MULT TOP 16TSSOP
- Product Category: Integrated Circuits (ICs)~PMIC - AC DC Converters, Offline Switchers
- Package: Tape & Reel (TR),Cut Tape (CT)
- Series: -
- PartStatus: Active
- OutputIsolation: Isolated
- InternalSwitch(s): No
- Voltage-Breakdown: -
- Topology: Boost, Flyback, Forward
- Voltage-StartUp: 4.6 V
- Voltage-Supply(Vcc/Vdd): 3.8V ~ 15V
- DutyCycle: 85%
- Frequency-Switching: 1MHz
- Power(Watts): -
- FaultProtection: Current Limiting, Over Temperature, Over Voltage
- ControlFeatures: Frequency Control, Soft Start, Sync
- OperatingTemperature: -40°C ~ 125°C (TJ)
- Package/Case: 16-TSSOP (0.173, 4.40mm Width)
- NCP1294EDBR2G onsemi (ON), IC OFFLINE SW MULT TOP 16TSSOP, Integrated Circuits (ICs)~PMIC - AC DC Converters, Offline Switchers
NCP1294EDBR2G, onsemi authentic parts in stock from onsemi (ON) authorized distributors, order today, can ship immediately.
