SCH2825-TL-E Images
- Manufacturer: onsemi (ON)
- Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single SupplierDevicePackage: 6-SCH
- Description: MOSFET N-CH 30V 1.6A 6SCH
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
SCH2825-TL-E Specifications:
- MfrPart.: SCH2825-TL-E
- Mfr: onsemi
- Description: MOSFET N-CH 30V 1.6A 6SCH
- Product Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
- Package: Tape & Reel (TR),Cut Tape (CT)
- Series: -
- PartStatus: Obsolete
- FETType: N-Channel
- Technology: MOSFET (Metal Oxide)
- DraintoSourceVoltage(Vdss): 30 V
- Current-ContinuousDrain(Id)@25°C: 1.6A (Ta)
- DriveVoltage(MaxRdsOnMinRdsOn): 4V, 10V
- RdsOn(Max)@IdVgs: 180mOhm @ 800mA, 10V
- Vgs(th)(Max)@Id: -
- GateCharge(Qg)(Max)@Vgs: 2 nC @ 10 V
- Vgs(Max): ±20V
- InputCapacitance(Ciss)(Max)@Vds: 88 pF @ 10 V
- FETFeature: Schottky Diode (Isolated)
- PowerDissipation(Max): 600mW (Ta)
- OperatingTemperature: -55°C ~ 125°C (TJ)
- MountingType: Surface Mount
- SupplierDevicePackage: 6-SCH
- SCH2825-TL-E onsemi (ON), MOSFET N-CH 30V 1.6A 6SCH, Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
