NTMFS10N7D2C Images
- Manufacturer: onsemi (ON)
- Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single SupplierDevicePackage: 8-PQFN (5x6), Power56
- Description: MOSFET N-CH 100V 78A 8PQFN
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
NTMFS10N7D2C Specifications:
- MfrPart.: NTMFS10N7D2C
- Mfr: onsemi
- Description: MOSFET N-CH 100V 78A 8PQFN
- Product Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
- Package: Tape & Reel (TR)
- Series: PowerTrench®
- PartStatus: Active
- FETType: N-Channel
- Technology: MOSFET (Metal Oxide)
- DraintoSourceVoltage(Vdss): 100 V
- Current-ContinuousDrain(Id)@25°C: 78A (Tc)
- DriveVoltage(MaxRdsOnMinRdsOn): 6V, 10V
- RdsOn(Max)@IdVgs: 7.2mOhm @ 28A, 10V
- Vgs(th)(Max)@Id: 4V @ 150µA
- GateCharge(Qg)(Max)@Vgs: 37 nC @ 10 V
- Vgs(Max): ±20V
- InputCapacitance(Ciss)(Max)@Vds: 2635 pF @ 50 V
- FETFeature: -
- PowerDissipation(Max): 83W (Tc)
- OperatingTemperature: -55°C ~ 150°C (TJ)
- MountingType: Surface Mount
- SupplierDevicePackage: 8-PQFN (5x6), Power56
- NTMFS10N7D2C onsemi (ON), MOSFET N-CH 100V 78A 8PQFN, Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
