NVMTSC1D3N08M7TXG Images
- Manufacturer: onsemi (ON)
- Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single SupplierDevicePackage: 8-DFNW (8.3x8.4)
- Description: MOSFET N-CH 80V 46A/348A 8DFNW
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
NVMTSC1D3N08M7TXG Specifications:
- MfrPart.: NVMTSC1D3N08M7TXG
- Mfr: onsemi
- Description: MOSFET N-CH 80V 46A/348A 8DFNW
- Product Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
- Package: Tape & Reel (TR)
- Series: Automotive, AEC-Q101
- PartStatus: Active
- FETType: N-Channel
- Technology: MOSFET (Metal Oxide)
- DraintoSourceVoltage(Vdss): 80 V
- Current-ContinuousDrain(Id)@25°C: 46A (Ta), 348A (Tc)
- DriveVoltage(MaxRdsOnMinRdsOn): 10V
- RdsOn(Max)@IdVgs: 1.25mOhm @ 80A, 10V
- Vgs(th)(Max)@Id: 4V @ 250µA
- GateCharge(Qg)(Max)@Vgs: 196 nC @ 10 V
- Vgs(Max): ±20V
- InputCapacitance(Ciss)(Max)@Vds: 14530 pF @ 40 V
- FETFeature: -
- PowerDissipation(Max): 5.1W (Ta), 287W (Tc)
- OperatingTemperature: -55°C ~ 175°C (TJ)
- MountingType: Surface Mount
- SupplierDevicePackage: 8-DFNW (8.3x8.4)
- NVMTSC1D3N08M7TXG onsemi (ON), MOSFET N-CH 80V 46A/348A 8DFNW, Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
NVMTSC1D3N08M7TXG, onsemi authentic parts in stock from onsemi (ON) authorized distributors, order today, can ship immediately.
