NCV7703D2G Images
- Manufacturer: onsemi (ON)
- Category: Integrated Circuits (ICs)~PMIC - Full, Half-Bridge Drivers Package/Case: 14-SOIC (0.154, 3.90mm Width)
- Description: IC DRVR HALF BRIDGE TRPL 14-SOIC
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
NCV7703D2G Specifications:
- MfrPart.: NCV7703D2G
- Mfr: onsemi
- Description: IC DRVR HALF BRIDGE TRPL 14-SOIC
- Product Category: Integrated Circuits (ICs)~PMIC - Full, Half-Bridge Drivers
- Package: Tube
- Series: -
- PartStatus: Obsolete
- OutputConfiguration: Half Bridge (3)
- Applications: DC Motors, General Purpose
- Interface: SPI
- LoadType: Inductive
- Technology: Power MOSFET
- RdsOn(Typ): 800mOhm LS, 800mOhm HS
- Current-Output/Channel: 500mA
- Current-PeakOutput: 1A
- Voltage-Supply: 3V ~ 5.25V
- Voltage-Load: 5.5V ~ 40V
- OperatingTemperature: -40°C ~ 150°C (TJ)
- Features: -
- FaultProtection: Current Limiting, ESD, Over Temperature, Over Voltage, UVLO
- MountingType: Surface Mount
- Package/Case: 14-SOIC (0.154, 3.90mm Width)
- NCV7703D2G onsemi (ON), IC DRVR HALF BRIDGE TRPL 14-SOIC, Integrated Circuits (ICs)~PMIC - Full, Half-Bridge Drivers
