NVMFS4C05NWFT1G onsemi MOSFET N-CH 30V 24.7A/116A 5DFN
NVMFS4C05NWFT1G Images
NVMFS4C05NWFT1G Images
  • Manufacturer: onsemi (ON)
  • Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single SupplierDevicePackage: 5-DFN (5x6) (8-SOFL)
  • Description: MOSFET N-CH 30V 24.7A/116A 5DFN
  • COMPETITIVE PRICE and DELIVERY TIME
  • Order with confidence, there are no lead times for in-stock products.
Quickly Quote for You to Meet Your Target Price, Support Small Order Quantity with Fast Quick Delivery.
Download Datasheet (PDF)
NVMFS4C05NWFT1G Datasheet
ELECTRONIC COMPONENTS, CHOOSE NHE ELECTRONICS
NVMFS4C05NWFT1G Specifications:
  • MfrPart.: NVMFS4C05NWFT1G
  • Mfr: onsemi
  • Description: MOSFET N-CH 30V 24.7A/116A 5DFN
  • Product Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
  • Package: Tape & Reel (TR),Cut Tape (CT)
  • Series: -
  • PartStatus: Active
  • FETType: N-Channel
  • Technology: MOSFET (Metal Oxide)
  • DraintoSourceVoltage(Vdss): 30 V
  • Current-ContinuousDrain(Id)@25°C: 24.7A (Ta), 116A (Tc)
  • DriveVoltage(MaxRdsOnMinRdsOn): 4.5V, 10V
  • RdsOn(Max)@IdVgs: 3.4mOhm @ 30A, 10V
  • Vgs(th)(Max)@Id: 2.2V @ 250µA
  • GateCharge(Qg)(Max)@Vgs: 30 nC @ 10 V
  • Vgs(Max): ±20V
  • InputCapacitance(Ciss)(Max)@Vds: 1972 pF @ 15 V
  • FETFeature: -
  • PowerDissipation(Max): 3.61W (Ta), 79W (Tc)
  • OperatingTemperature: -55°C ~ 175°C (TJ)
  • MountingType: Surface Mount
  • SupplierDevicePackage: 5-DFN (5x6) (8-SOFL)
  • NVMFS4C05NWFT1G onsemi (ON), MOSFET N-CH 30V 24.7A/116A 5DFN, Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
NVMFS4C05NWFT1G, onsemi authentic parts in stock from onsemi (ON) authorized distributors, order today, can ship immediately.
