FGA40S65SH Images
- Manufacturer: onsemi (ON)
- Category: Discrete Semiconductor Products~Transistors - IGBTs - Single Package/Case: TO-3P-3, SC-65-3
- Description: IGBT TRENCH/FS 650V 80A TO3PN
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
FGA40S65SH Specifications:
- MfrPart.: FGA40S65SH
- Mfr: onsemi
- Description: IGBT TRENCH/FS 650V 80A TO3PN
- Product Category: Discrete Semiconductor Products~Transistors - IGBTs - Single
- Package: Tube
- Series: -
- PartStatus: Obsolete
- IGBTType: Trench Field Stop
- Voltage-CollectorEmitterBreakdown(Max): 650 V
- Current-Collector(Ic)(Max): 80 A
- Current-CollectorPulsed(Icm): 120 A
- Vce(on)(Max)@VgeIc: 1.81V @ 15V, 40A
- Power-Max: 268 W
- SwitchingEnergy: 194µJ (on), 388µJ (off)
- InputType: Standard
- GateCharge: 73 nC
- Td(on/off)@25°C: 19.2ns/68.8ns
- TestCondition: 400V, 40A, 6Ohm, 15V
- ReverseRecoveryTime(trr): -
- OperatingTemperature: -55°C ~ 175°C (TJ)
- MountingType: Through Hole
- Package/Case: TO-3P-3, SC-65-3
- FGA40S65SH onsemi (ON), IGBT TRENCH/FS 650V 80A TO3PN, Discrete Semiconductor Products~Transistors - IGBTs - Single
