NVD5863NLT4G-VF01 Images
- Manufacturer: onsemi (ON)
- Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single SupplierDevicePackage: DPAK (SINGLE GAUGE)
- Description: MOSFET N-CH 60V 14.9A/82A DPAK
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
NVD5863NLT4G-VF01 Specifications:
- MfrPart.: NVD5863NLT4G-VF01
- Mfr: onsemi
- Description: MOSFET N-CH 60V 14.9A/82A DPAK
- Product Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
- Package: Tape & Reel (TR)
- Series: Automotive, AEC-Q101
- PartStatus: Active
- FETType: N-Channel
- Technology: MOSFET (Metal Oxide)
- DraintoSourceVoltage(Vdss): 60 V
- Current-ContinuousDrain(Id)@25°C: 14.9A (Ta), 82A (Tc)
- DriveVoltage(MaxRdsOnMinRdsOn): 4.5V, 10V
- RdsOn(Max)@IdVgs: 7.1mOhm @ 41A, 10V
- Vgs(th)(Max)@Id: 3V @ 250µA
- GateCharge(Qg)(Max)@Vgs: 70 nC @ 10 V
- Vgs(Max): ±20V
- InputCapacitance(Ciss)(Max)@Vds: 3850 pF @ 25 V
- FETFeature: -
- PowerDissipation(Max): 3.1W (Ta), 96W (Tc)
- OperatingTemperature: -55°C ~ 175°C (TJ)
- MountingType: Surface Mount
- SupplierDevicePackage: DPAK (SINGLE GAUGE)
- NVD5863NLT4G-VF01 onsemi (ON), MOSFET N-CH 60V 14.9A/82A DPAK, Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
NVD5863NLT4G-VF01, onsemi authentic parts in stock from onsemi (ON) authorized distributors, order today, can ship immediately.
