HMHA2801BR2V Images
- Manufacturer: onsemi (ON)
- Category: Isolators~Optoisolators - Transistor, Photovoltaic Output Package/Case: 4-SOIC (0.173, 4.40mm Width)
- Description: OPTOISO 3.75KV TRANSISTOR 4SMD
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
HMHA2801BR2V Specifications:
- MfrPart.: HMHA2801BR2V
- Mfr: onsemi
- Description: OPTOISO 3.75KV TRANSISTOR 4SMD
- Product Category: Isolators~Optoisolators - Transistor, Photovoltaic Output
- Package: Tape & Reel (TR)
- Series: -
- PartStatus: Obsolete
- NumberofChannels: 1
- Voltage-Isolation: 3750Vrms
- CurrentTransferRatio(Min): 130% @ 5mA
- CurrentTransferRatio(Max): 260% @ 5mA
- TurnOn/TurnOffTime(Typ): -
- Rise/FallTime(Typ): 3µs, 3µs
- InputType: DC
- OutputType: Transistor
- Voltage-Output(Max): 80V
- Current-Output/Channel: 50mA
- Voltage-Forward(Vf)(Typ): 1.3V (Max)
- Current-DCForward(If)(Max): 50 mA
- VceSaturation(Max): 300mV
- OperatingTemperature: -55°C ~ 100°C
- MountingType: Surface Mount
- Package/Case: 4-SOIC (0.173, 4.40mm Width)
- HMHA2801BR2V onsemi (ON), OPTOISO 3.75KV TRANSISTOR 4SMD, Isolators~Optoisolators - Transistor, Photovoltaic Output
HMHA2801BR2V, onsemi authentic parts in stock from onsemi (ON) authorized distributors, order today, can ship immediately.
