NTNS3A91PZT5G Images
- Manufacturer: onsemi (ON)
- Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single SupplierDevicePackage: 3-XLLGA (0.62x0.62)
- Description: MOSFET P-CH 20V 223MA 3XLLGA
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
NTNS3A91PZT5G Specifications:
- MfrPart.: NTNS3A91PZT5G
- Mfr: onsemi
- Description: MOSFET P-CH 20V 223MA 3XLLGA
- Product Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
- Package: Tape & Reel (TR),Cut Tape (CT)
- Series: -
- PartStatus: Active
- FETType: P-Channel
- Technology: MOSFET (Metal Oxide)
- DraintoSourceVoltage(Vdss): 20 V
- Current-ContinuousDrain(Id)@25°C: 223mA (Ta)
- DriveVoltage(MaxRdsOnMinRdsOn): 1.5V, 4.5V
- RdsOn(Max)@IdVgs: 1.6Ohm @ 100mA, 4.5V
- Vgs(th)(Max)@Id: 1V @ 250µA
- GateCharge(Qg)(Max)@Vgs: 1.1 nC @ 4.5 V
- Vgs(Max): ±8V
- InputCapacitance(Ciss)(Max)@Vds: 41 pF @ 15 V
- FETFeature: -
- PowerDissipation(Max): 121mW (Ta)
- OperatingTemperature: -55°C ~ 150°C (TJ)
- MountingType: Surface Mount
- SupplierDevicePackage: 3-XLLGA (0.62x0.62)
- NTNS3A91PZT5G onsemi (ON), MOSFET P-CH 20V 223MA 3XLLGA, Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
