NVMFS5C420NLT1G Images
- Manufacturer: onsemi (ON)
- Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single SupplierDevicePackage: Surface Mount
- Description: POWER MOSFET, SINGLE, N-CHANNEL
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
NVMFS5C420NLT1G Specifications:
- MfrPart.: NVMFS5C420NLT1G
- Mfr: onsemi
- Description: POWER MOSFET, SINGLE, N-CHANNEL
- Product Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
- Package: 1
- Series: Tape & Reel (TR),Cut Tape (CT)
- PartStatus: Automotive, AEC-Q101
- FETType: Active
- Technology: N-Channel
- DraintoSourceVoltage(Vdss): MOSFET (Metal Oxide)
- Current-ContinuousDrain(Id)@25°C: 40 V
- DriveVoltage(MaxRdsOnMinRdsOn): 45A (Ta), 277A (Tc)
- RdsOn(Max)@IdVgs: 4.5V, 10V
- Vgs(th)(Max)@Id: 1mOhm @ 50A, 10V
- GateCharge(Qg)(Max)@Vgs: 2.2V @ 200µA
- Vgs(Max): 100 nC @ 10 V
- InputCapacitance(Ciss)(Max)@Vds: ±20V
- FETFeature: 7020 pF @ 20 V
- PowerDissipation(Max): -
- OperatingTemperature: 3.8W (Ta), 146W (Tc)
- MountingType: -55°C ~ 175°C (TJ)
- SupplierDevicePackage: Surface Mount
- NVMFS5C420NLT1G onsemi (ON), POWER MOSFET, SINGLE, N-CHANNEL, Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
NVMFS5C420NLT1G, onsemi authentic parts in stock from onsemi (ON) authorized distributors, order today, can ship immediately.
