NTMFS4C59NT1G Images
- Manufacturer: onsemi (ON)
- Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single SupplierDevicePackage: 5-DFN (5x6) (8-SOFL)
- Description: MOSFET N-CH 30V 9A/52A 5DFN
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
NTMFS4C59NT1G Specifications:
- MfrPart.: NTMFS4C59NT1G
- Mfr: onsemi
- Description: MOSFET N-CH 30V 9A/52A 5DFN
- Product Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
- Package: Tape & Reel (TR),Cut Tape (CT)
- Series: -
- PartStatus: Active
- FETType: N-Channel
- Technology: MOSFET (Metal Oxide)
- DraintoSourceVoltage(Vdss): 30 V
- Current-ContinuousDrain(Id)@25°C: 9A (Ta), 52A (Tc)
- DriveVoltage(MaxRdsOnMinRdsOn): 4.5V, 10V
- RdsOn(Max)@IdVgs: 5.8mOhm @ 30A, 10V
- Vgs(th)(Max)@Id: 2.1V @ 250µA
- GateCharge(Qg)(Max)@Vgs: 22.2 nC @ 10 V
- Vgs(Max): ±20V
- InputCapacitance(Ciss)(Max)@Vds: 1252 pF @ 15 V
- FETFeature: -
- PowerDissipation(Max): 760mW (Ta)
- OperatingTemperature: -55°C ~ 150°C (TJ)
- MountingType: Surface Mount
- SupplierDevicePackage: 5-DFN (5x6) (8-SOFL)
- NTMFS4C59NT1G onsemi (ON), MOSFET N-CH 30V 9A/52A 5DFN, Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
NTMFS4C59NT1G, onsemi authentic parts in stock from onsemi (ON) authorized distributors, order today, can ship immediately.
