MCH3477-TL-H Images
- Manufacturer: onsemi (ON)
- Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single SupplierDevicePackage: SC-70FL/MCPH3
- Description: MOSFET N-CH 20V 4.5A SC70
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
MCH3477-TL-H Specifications:
- MfrPart.: MCH3477-TL-H
- Mfr: onsemi
- Description: MOSFET N-CH 20V 4.5A SC70
- Product Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
- Package: Tape & Reel (TR)
- Series: -
- PartStatus: Not For New Designs
- FETType: N-Channel
- Technology: MOSFET (Metal Oxide)
- DraintoSourceVoltage(Vdss): 20 V
- Current-ContinuousDrain(Id)@25°C: 4.5A (Ta)
- DriveVoltage(MaxRdsOnMinRdsOn): 1.8V, 4.5V
- RdsOn(Max)@IdVgs: 38mOhm @ 2A, 4.5V
- Vgs(th)(Max)@Id: -
- GateCharge(Qg)(Max)@Vgs: 5.1 nC @ 4.5 V
- Vgs(Max): ±12V
- InputCapacitance(Ciss)(Max)@Vds: 410 pF @ 10 V
- FETFeature: -
- PowerDissipation(Max): 1W (Ta)
- OperatingTemperature: 150°C (TJ)
- MountingType: Surface Mount
- SupplierDevicePackage: SC-70FL/MCPH3
- MCH3477-TL-H onsemi (ON), MOSFET N-CH 20V 4.5A SC70, Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
