NTD23N03RT4 Images
- Manufacturer: onsemi (ON)
- Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single SupplierDevicePackage: DPAK
- Description: MOSFET N-CH 25V 3.8A/17.1A DPAK
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
NTD23N03RT4 Specifications:
- MfrPart.: NTD23N03RT4
- Mfr: onsemi
- Description: MOSFET N-CH 25V 3.8A/17.1A DPAK
- Product Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
- Package: Tape & Reel (TR),Cut Tape (CT)
- Series: -
- PartStatus: Obsolete
- FETType: N-Channel
- Technology: MOSFET (Metal Oxide)
- DraintoSourceVoltage(Vdss): 25 V
- Current-ContinuousDrain(Id)@25°C: 3.8A (Ta), 17.1A (Tc)
- DriveVoltage(MaxRdsOnMinRdsOn): 4V, 5V
- RdsOn(Max)@IdVgs: 45mOhm @ 6A, 10V
- Vgs(th)(Max)@Id: 2V @ 250µA
- GateCharge(Qg)(Max)@Vgs: 3.76 nC @ 4.5 V
- Vgs(Max): ±20V
- InputCapacitance(Ciss)(Max)@Vds: 225 pF @ 20 V
- FETFeature: -
- PowerDissipation(Max): 1.14W (Ta), 22.3W (Tc)
- OperatingTemperature: -55°C ~ 150°C (TJ)
- MountingType: Surface Mount
- SupplierDevicePackage: DPAK
- NTD23N03RT4 onsemi (ON), MOSFET N-CH 25V 3.8A/17.1A DPAK, Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
