NCV1117STAT3 Images
- Manufacturer: onsemi (ON)
- Category: Integrated Circuits (ICs)~PMIC - Voltage Regulators - Linear Package/Case: TO-261-4, TO-261AA
- Description: IC REG LINEAR POS ADJ 1A SOT223
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
NCV1117STAT3 Specifications:
- MfrPart.: NCV1117STAT3
- Mfr: onsemi
- Description: IC REG LINEAR POS ADJ 1A SOT223
- Product Category: Integrated Circuits (ICs)~PMIC - Voltage Regulators - Linear
- Package: Tape & Reel (TR)
- Series: Automotive, AEC-Q100
- PartStatus: Obsolete
- OutputConfiguration: Positive
- OutputType: Adjustable
- NumberofRegulators: 1
- Voltage-Input(Max): 20V
- Voltage-Output(Min/Fixed): 1.25V
- Voltage-Output(Max): 18.8V
- VoltageDropout(Max): 1.2V @ 800mA
- Current-Output: 1A
- Current-Quiescent(Iq): 10 mA
- Current-Supply(Max): -
- PSRR: 73dB (120Hz)
- ControlFeatures: -
- ProtectionFeatures: Over Current, Over Temperature
- OperatingTemperature: -40°C ~ 125°C (TA)
- MountingType: Surface Mount
- Package/Case: TO-261-4, TO-261AA
- NCV1117STAT3 onsemi (ON), IC REG LINEAR POS ADJ 1A SOT223, Integrated Circuits (ICs)~PMIC - Voltage Regulators - Linear
NCV1117STAT3, onsemi authentic parts in stock from onsemi (ON) authorized distributors, order today, can ship immediately.
