NTB75N03R Images
- Manufacturer: onsemi (ON)
- Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single SupplierDevicePackage: D²PAK
- Description: MOSFET N-CH 25V 9.7A/75A D2PAK
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
NTB75N03R Specifications:
- MfrPart.: NTB75N03R
- Mfr: onsemi
- Description: MOSFET N-CH 25V 9.7A/75A D2PAK
- Product Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
- Package: Tube
- Series: -
- PartStatus: Obsolete
- FETType: N-Channel
- Technology: MOSFET (Metal Oxide)
- DraintoSourceVoltage(Vdss): 25 V
- Current-ContinuousDrain(Id)@25°C: 9.7A (Ta), 75A (Tc)
- DriveVoltage(MaxRdsOnMinRdsOn): 4.5V, 10V
- RdsOn(Max)@IdVgs: 8mOhm @ 20A, 10V
- Vgs(th)(Max)@Id: 2V @ 250µA
- GateCharge(Qg)(Max)@Vgs: 13.2 nC @ 10 V
- Vgs(Max): ±20V
- InputCapacitance(Ciss)(Max)@Vds: 1333 pF @ 20 V
- FETFeature: -
- PowerDissipation(Max): 1.25W (Ta), 74.4W (Tc)
- OperatingTemperature: -55°C ~ 150°C (TJ)
- MountingType: Surface Mount
- SupplierDevicePackage: D²PAK
- NTB75N03R onsemi (ON), MOSFET N-CH 25V 9.7A/75A D2PAK, Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
NTB75N03R, onsemi authentic parts in stock from onsemi (ON) authorized distributors, order today, can ship immediately.
