FCU4300N80Z Images
- Manufacturer: onsemi (ON)
- Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single SupplierDevicePackage: I-PAK
- Description: MOSFET N-CH 800V 1.6A IPAK
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
FCU4300N80Z Specifications:
- MfrPart.: FCU4300N80Z
- Mfr: onsemi
- Description: MOSFET N-CH 800V 1.6A IPAK
- Product Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
- Package: Tube
- Series: SuperFET® II
- PartStatus: Active
- FETType: N-Channel
- Technology: MOSFET (Metal Oxide)
- DraintoSourceVoltage(Vdss): 800 V
- Current-ContinuousDrain(Id)@25°C: 1.6A (Tc)
- DriveVoltage(MaxRdsOnMinRdsOn): 10V
- RdsOn(Max)@IdVgs: 4.3Ohm @ 800mA, 10V
- Vgs(th)(Max)@Id: 4.5V @ 160µA
- GateCharge(Qg)(Max)@Vgs: 8.8 nC @ 10 V
- Vgs(Max): ±20V
- InputCapacitance(Ciss)(Max)@Vds: 355 pF @ 100 V
- FETFeature: -
- PowerDissipation(Max): 27.8W (Tc)
- OperatingTemperature: -55°C ~ 150°C (TJ)
- MountingType: Through Hole
- SupplierDevicePackage: I-PAK
- FCU4300N80Z onsemi (ON), MOSFET N-CH 800V 1.6A IPAK, Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
FCU4300N80Z, onsemi authentic parts in stock from onsemi (ON) authorized distributors, order today, can ship immediately.
