NTB23N03RT4G Images
- Manufacturer: onsemi (ON)
- Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single SupplierDevicePackage: D²PAK
- Description: MOSFET N-CH 25V 23A D2PAK
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
NTB23N03RT4G Specifications:
- MfrPart.: NTB23N03RT4G
- Mfr: onsemi
- Description: MOSFET N-CH 25V 23A D2PAK
- Product Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
- Package: Tape & Reel (TR),Cut Tape (CT)
- Series: -
- PartStatus: Obsolete
- FETType: N-Channel
- Technology: MOSFET (Metal Oxide)
- DraintoSourceVoltage(Vdss): 25 V
- Current-ContinuousDrain(Id)@25°C: 23A (Ta)
- DriveVoltage(MaxRdsOnMinRdsOn): 4.5V, 10V
- RdsOn(Max)@IdVgs: 45mOhm @ 6A, 10V
- Vgs(th)(Max)@Id: 2V @ 250µA
- GateCharge(Qg)(Max)@Vgs: 3.76 nC @ 4.5 V
- Vgs(Max): ±20V
- InputCapacitance(Ciss)(Max)@Vds: 225 pF @ 20 V
- FETFeature: -
- PowerDissipation(Max): 37.5W (Tj)
- OperatingTemperature: -55°C ~ 150°C (TJ)
- MountingType: Surface Mount
- SupplierDevicePackage: D²PAK
- NTB23N03RT4G onsemi (ON), MOSFET N-CH 25V 23A D2PAK, Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
NTB23N03RT4G, onsemi authentic parts in stock from onsemi (ON) authorized distributors, order today, can ship immediately.
