NSVMUN5314DW1T3G Images
- Manufacturer: onsemi (ON)
- Category: Discrete Semiconductor Products~Transistors - Bipolar (BJT) - Arrays, Pre-Biased Package/Case: 6-TSSOP, SC-88, SOT-363
- Description: TRANS NPN/PNP 50V BIPO SC88-6
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
NSVMUN5314DW1T3G Specifications:
- MfrPart.: NSVMUN5314DW1T3G
- Mfr: onsemi
- Description: TRANS NPN/PNP 50V BIPO SC88-6
- Product Category: Discrete Semiconductor Products~Transistors - Bipolar (BJT) - Arrays, Pre-Biased
- Package: Tape & Reel (TR)
- Series: -
- PartStatus: Active
- TransistorType: 1 NPN, 1 PNP - Pre-Biased (Dual)
- Current-Collector(Ic)(Max): 100mA
- Voltage-CollectorEmitterBreakdown(Max): 50V
- Resistor-Base(R1): 10kOhms
- Resistor-EmitterBase(R2): 47kOhms
- DCCurrentGain(hFE)(Min)@IcVce: 80 @ 5mA, 10V
- VceSaturation(Max)@IbIc: 250mV @ 300µA, 10mA
- Current-CollectorCutoff(Max): 500nA
- Frequency-Transition: -
- Power-Max: 250mW
- MountingType: Surface Mount
- Package/Case: 6-TSSOP, SC-88, SOT-363
- NSVMUN5314DW1T3G onsemi (ON), TRANS NPN/PNP 50V BIPO SC88-6, Discrete Semiconductor Products~Transistors - Bipolar (BJT) - Arrays, Pre-Biased
