NTD4302-001 Images
- Manufacturer: onsemi (ON)
- Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single SupplierDevicePackage: DPAK
- Description: MOSFET N-CH 30V 8.4A/68A DPAK
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
NTD4302-001 Specifications:
- MfrPart.: NTD4302-001
- Mfr: onsemi
- Description: MOSFET N-CH 30V 8.4A/68A DPAK
- Product Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
- Package: Bulk
- Series: -
- PartStatus: Obsolete
- FETType: N-Channel
- Technology: MOSFET (Metal Oxide)
- DraintoSourceVoltage(Vdss): 30 V
- Current-ContinuousDrain(Id)@25°C: 8.4A (Ta), 68A (Tc)
- DriveVoltage(MaxRdsOnMinRdsOn): -
- RdsOn(Max)@IdVgs: 10mOhm @ 20A, 10V
- Vgs(th)(Max)@Id: 3V @ 250µA
- GateCharge(Qg)(Max)@Vgs: 80 nC @ 10 V
- Vgs(Max): ±20V
- InputCapacitance(Ciss)(Max)@Vds: 2400 pF @ 24 V
- FETFeature: -
- PowerDissipation(Max): 1.04W (Ta), 75W (Tc)
- OperatingTemperature: -55°C ~ 150°C (TJ)
- MountingType: Surface Mount
- SupplierDevicePackage: DPAK
- NTD4302-001 onsemi (ON), MOSFET N-CH 30V 8.4A/68A DPAK, Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
