NGTG25N120FL2WG Images
- Manufacturer: onsemi (ON)
- Category: Discrete Semiconductor Products~Transistors - IGBTs - Single Package/Case: TO-247-3
- Description: IGBT 1200V 25A TO-247
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
NGTG25N120FL2WG Specifications:
- MfrPart.: NGTG25N120FL2WG
- Mfr: onsemi
- Description: IGBT 1200V 25A TO-247
- Product Category: Discrete Semiconductor Products~Transistors - IGBTs - Single
- Package: Tube
- Series: -
- PartStatus: Obsolete
- IGBTType: Trench Field Stop
- Voltage-CollectorEmitterBreakdown(Max): 1200 V
- Current-Collector(Ic)(Max): 50 A
- Current-CollectorPulsed(Icm): 100 A
- Vce(on)(Max)@VgeIc: 2.4V @ 15V, 25A
- Power-Max: 385 W
- SwitchingEnergy: 1.95mJ (on), 600µJ (off)
- InputType: Standard
- GateCharge: 178 nC
- Td(on/off)@25°C: 87ns/179ns
- TestCondition: 600V, 25A, 10Ohm, 15V
- ReverseRecoveryTime(trr): -
- OperatingTemperature: -55°C ~ 175°C (TJ)
- MountingType: Through Hole
- Package/Case: TO-247-3
- NGTG25N120FL2WG onsemi (ON), IGBT 1200V 25A TO-247, Discrete Semiconductor Products~Transistors - IGBTs - Single
