FAN7842MX Images
- Manufacturer: onsemi (ON)
- Category: Integrated Circuits (ICs)~PMIC - Gate Drivers Package/Case: 8-SOIC (0.154, 3.90mm Width)
- Description: IC GATE DRVR HALF-BRIDGE 8SOIC
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
FAN7842MX Specifications:
- MfrPart.: FAN7842MX
- Mfr: onsemi
- Description: IC GATE DRVR HALF-BRIDGE 8SOIC
- Product Category: Integrated Circuits (ICs)~PMIC - Gate Drivers
- Package: Tape & Reel (TR),Cut Tape (CT)
- Series: -
- PartStatus: Active
- DrivenConfiguration: Half-Bridge
- ChannelType: Independent
- NumberofDrivers: 2
- GateType: IGBT, N-Channel MOSFET
- Voltage-Supply: 10V ~ 20V
- LogicVoltage-VILVIH: 0.8V, 2.9V
- Current-PeakOutput(SourceSink): 350mA, 650mA
- InputType: Non-Inverting
- HighSideVoltage-Max(Bootstrap): 200 V
- Rise/FallTime(Typ): 60ns, 30ns
- OperatingTemperature: -40°C ~ 150°C (TJ)
- MountingType: Surface Mount
- Package/Case: 8-SOIC (0.154, 3.90mm Width)
- FAN7842MX onsemi (ON), IC GATE DRVR HALF-BRIDGE 8SOIC, Integrated Circuits (ICs)~PMIC - Gate Drivers
