NDS336P Images
- Manufacturer: onsemi (ON)
- Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single SupplierDevicePackage: SOT-23-3
- Description: MOSFET P-CH 20V 1.2A SUPERSOT3
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
NDS336P Specifications:
- MfrPart.: NDS336P
- Mfr: onsemi
- Description: MOSFET P-CH 20V 1.2A SUPERSOT3
- Product Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
- Package: Tape & Reel (TR),Cut Tape (CT)
- Series: -
- PartStatus: Obsolete
- FETType: P-Channel
- Technology: MOSFET (Metal Oxide)
- DraintoSourceVoltage(Vdss): 20 V
- Current-ContinuousDrain(Id)@25°C: 1.2A (Ta)
- DriveVoltage(MaxRdsOnMinRdsOn): 2.7V, 4.5V
- RdsOn(Max)@IdVgs: 200mOhm @ 1.3A, 4.5V
- Vgs(th)(Max)@Id: 1V @ 250µA
- GateCharge(Qg)(Max)@Vgs: 8.5 nC @ 4.5 V
- Vgs(Max): ±8V
- InputCapacitance(Ciss)(Max)@Vds: 360 pF @ 10 V
- FETFeature: -
- PowerDissipation(Max): 500mW (Ta)
- OperatingTemperature: -55°C ~ 150°C (TJ)
- MountingType: Surface Mount
- SupplierDevicePackage: SOT-23-3
- NDS336P onsemi (ON), MOSFET P-CH 20V 1.2A SUPERSOT3, Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
