NTMD5836NLR2G Images
- Manufacturer: onsemi (ON)
- Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Arrays Package/Case: 8-SOIC (0.154, 3.90mm Width)
- Description: SMALL SIGNAL N-CHANNEL MOSFET
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
NTMD5836NLR2G Specifications:
- MfrPart.: NTMD5836NLR2G
- Mfr: onsemi
- Description: SMALL SIGNAL N-CHANNEL MOSFET
- Product Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Arrays
- Package: Bulk
- Series: -
- PartStatus: Obsolete
- FETType: 2 N-Channel (Dual)
- FETFeature: Logic Level Gate
- DraintoSourceVoltage(Vdss): 40V
- Current-ContinuousDrain(Id)@25°C: 9A, 5.7A
- RdsOn(Max)@IdVgs: 12mOhm @ 10A, 10V
- Vgs(th)(Max)@Id: 3V @ 250µA
- GateCharge(Qg)(Max)@Vgs: 50nC @ 10V
- InputCapacitance(Ciss)(Max)@Vds: 2120pF @ 20V
- Power-Max: 1.5W
- OperatingTemperature: -55°C ~ 150°C (TJ)
- MountingType: Surface Mount
- Package/Case: 8-SOIC (0.154, 3.90mm Width)
- NTMD5836NLR2G onsemi (ON), SMALL SIGNAL N-CHANNEL MOSFET, Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Arrays
NTMD5836NLR2G, onsemi authentic parts in stock from onsemi (ON) authorized distributors, order today, can ship immediately.
