NCV57001DWR2G Images
- Manufacturer: onsemi (ON)
- Category: Isolators~Isolators - Gate Drivers Package/Case: 16-SOIC (0.295, 7.50mm Width)
- Description: IC IGBT GATE DRIVER
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
NCV57001DWR2G Specifications:
- MfrPart.: NCV57001DWR2G
- Mfr: onsemi
- Description: IC IGBT GATE DRIVER
- Product Category: Isolators~Isolators - Gate Drivers
- Package: Tape & Reel (TR),Cut Tape (CT)
- Series: Automotive, AEC-Q100
- PartStatus: Active
- Technology: Capacitive Coupling
- NumberofChannels: 1
- Voltage-Isolation: 1200Vrms
- CommonModeTransientImmunity(Min): 100kV/µs
- PropagationDelaytpLH/tpHL(Max): 90ns, 90ns
- PulseWidthDistortion(Max): -
- Rise/FallTime(Typ): 10ns, 15ns
- Current-OutputHighLow: 7.8A, 7.1A
- Current-PeakOutput: -
- Voltage-Forward(Vf)(Typ): -
- Current-DCForward(If)(Max): -
- Voltage-OutputSupply: 0V ~ 24V
- OperatingTemperature: -40°C ~ 125°C (TA)
- MountingType: Surface Mount
- Package/Case: 16-SOIC (0.295, 7.50mm Width)
- NCV57001DWR2G onsemi (ON), IC IGBT GATE DRIVER, Isolators~Isolators - Gate Drivers
