NGTB25N120IHLWG Images
- Manufacturer: onsemi (ON)
- Category: Discrete Semiconductor Products~Transistors - IGBTs - Single Package/Case: TO-247-3
- Description: IGBT 1200V 50A TO247
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
NGTB25N120IHLWG Specifications:
- MfrPart.: NGTB25N120IHLWG
- Mfr: onsemi
- Description: IGBT 1200V 50A TO247
- Product Category: Discrete Semiconductor Products~Transistors - IGBTs - Single
- Package: Tube
- Series: -
- PartStatus: Obsolete
- IGBTType: -
- Voltage-CollectorEmitterBreakdown(Max): 1200 V
- Current-Collector(Ic)(Max): 50 A
- Current-CollectorPulsed(Icm): 200 A
- Vce(on)(Max)@VgeIc: 2.3V @ 15V, 25A
- Power-Max: 192 W
- SwitchingEnergy: 800µJ (off)
- InputType: Standard
- GateCharge: 200 nC
- Td(on/off)@25°C: -/235ns
- TestCondition: 600V, 25A, 10Ohm, 15V
- ReverseRecoveryTime(trr): -
- OperatingTemperature: -55°C ~ 150°C (TJ)
- MountingType: Through Hole
- Package/Case: TO-247-3
- NGTB25N120IHLWG onsemi (ON), IGBT 1200V 50A TO247, Discrete Semiconductor Products~Transistors - IGBTs - Single
