FDS6614A Images
- Manufacturer: onsemi (ON)
- Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single SupplierDevicePackage: 8-SOIC
- Description: MOSFET N-CH 30V 9.3A 8SOIC
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
FDS6614A Specifications:
- MfrPart.: FDS6614A
- Mfr: onsemi
- Description: MOSFET N-CH 30V 9.3A 8SOIC
- Product Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
- Package: Tape & Reel (TR)
- Series: PowerTrench®
- PartStatus: Obsolete
- FETType: N-Channel
- Technology: MOSFET (Metal Oxide)
- DraintoSourceVoltage(Vdss): 30 V
- Current-ContinuousDrain(Id)@25°C: 9.3A (Ta)
- DriveVoltage(MaxRdsOnMinRdsOn): 4.5V, 10V
- RdsOn(Max)@IdVgs: 18mOhm @ 9.3A, 10V
- Vgs(th)(Max)@Id: 3V @ 250µA
- GateCharge(Qg)(Max)@Vgs: 17 nC @ 5 V
- Vgs(Max): ±20V
- InputCapacitance(Ciss)(Max)@Vds: 1160 pF @ 15 V
- FETFeature: -
- PowerDissipation(Max): 2.5W (Ta)
- OperatingTemperature: -55°C ~ 150°C (TJ)
- MountingType: Surface Mount
- SupplierDevicePackage: 8-SOIC
- FDS6614A onsemi (ON), MOSFET N-CH 30V 9.3A 8SOIC, Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
