NCP5106APG onsemi IC GATE DRVR HALF-BRIDGE 8DIP
NCP5106APG Images
NCP5106APG Images
NCP5106APG
  • Manufacturer: onsemi (ON)
  • Category: Integrated Circuits (ICs)~PMIC - Gate Drivers Package/Case: 8-DIP (0.300, 7.62mm)
  • Description: IC GATE DRVR HALF-BRIDGE 8DIP
  • COMPETITIVE PRICE and DELIVERY TIME
  • Order with confidence, there are no lead times for in-stock products.
Quickly Quote for You to Meet Your Target Price, Support Small Order Quantity with Fast Quick Delivery.
Download Datasheet (PDF)
NCP5106APG Datasheet
ELECTRONIC COMPONENTS, CHOOSE NHE ELECTRONICS
NCP5106APG Specifications:
  • MfrPart.: NCP5106APG
  • Mfr: onsemi
  • Description: IC GATE DRVR HALF-BRIDGE 8DIP
  • Product Category: Integrated Circuits (ICs)~PMIC - Gate Drivers
  • Package: Tube
  • Series: -
  • PartStatus: Obsolete
  • DrivenConfiguration: Half-Bridge
  • ChannelType: Independent
  • NumberofDrivers: 2
  • GateType: IGBT, N-Channel MOSFET
  • Voltage-Supply: 10V ~ 20V
  • LogicVoltage-VILVIH: 0.8V, 2.3V
  • Current-PeakOutput(SourceSink): 250mA, 500mA
  • InputType: Non-Inverting
  • HighSideVoltage-Max(Bootstrap): 600 V
  • Rise/FallTime(Typ): 85ns, 35ns
  • OperatingTemperature: -40°C ~ 125°C (TJ)
  • MountingType: Through Hole
  • Package/Case: 8-DIP (0.300, 7.62mm)
  • NCP5106APG onsemi (ON), IC GATE DRVR HALF-BRIDGE 8DIP, Integrated Circuits (ICs)~PMIC - Gate Drivers
