MMBTA56WT1G Images
- Manufacturer: onsemi (ON)
- Category: Discrete Semiconductor Products~Transistors - Bipolar (BJT) - Single Package/Case: SC-70, SOT-323
- Description: TRANS PNP 80V 500MA SC70-3
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
MMBTA56WT1G Specifications:
- MfrPart.: MMBTA56WT1G
- Mfr: onsemi
- Description: TRANS PNP 80V 500MA SC70-3
- Product Category: Discrete Semiconductor Products~Transistors - Bipolar (BJT) - Single
- Package: Tape & Reel (TR),Cut Tape (CT)
- Series: -
- PartStatus: Active
- TransistorType: PNP
- Current-Collector(Ic)(Max): 500 mA
- Voltage-CollectorEmitterBreakdown(Max): 80 V
- VceSaturation(Max)@IbIc: 250mV @ 10mA, 100mA
- Current-CollectorCutoff(Max): 100nA
- DCCurrentGain(hFE)(Min)@IcVce: 100 @ 100mA, 1V
- Power-Max: 150 mW
- Frequency-Transition: 50MHz
- OperatingTemperature: -55°C ~ 150°C (TJ)
- MountingType: Surface Mount
- Package/Case: SC-70, SOT-323
- MMBTA56WT1G onsemi (ON), TRANS PNP 80V 500MA SC70-3, Discrete Semiconductor Products~Transistors - Bipolar (BJT) - Single
