HGT1S14N36G3VLS Images
- Manufacturer: onsemi (ON)
- Category: Discrete Semiconductor Products~Transistors - IGBTs - Single Package/Case: TO-263-3, D²Pak (2 Leads + Tab), TO-263AB
- Description: IGBT 390V 18A 100W TO263AB
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
HGT1S14N36G3VLS Specifications:
- MfrPart.: HGT1S14N36G3VLS
- Mfr: onsemi
- Description: IGBT 390V 18A 100W TO263AB
- Product Category: Discrete Semiconductor Products~Transistors - IGBTs - Single
- Package: Tube
- Series: -
- PartStatus: Obsolete
- IGBTType: -
- Voltage-CollectorEmitterBreakdown(Max): 390 V
- Current-Collector(Ic)(Max): 18 A
- Current-CollectorPulsed(Icm): -
- Vce(on)(Max)@VgeIc: 2.2V @ 5V, 14A
- Power-Max: 100 W
- SwitchingEnergy: -
- InputType: Logic
- GateCharge: 24 nC
- Td(on/off)@25°C: -/7µs
- TestCondition: 300V, 7A, 25Ohm, 5V
- ReverseRecoveryTime(trr): -
- OperatingTemperature: -40°C ~ 175°C (TJ)
- MountingType: Surface Mount
- Package/Case: TO-263-3, D²Pak (2 Leads + Tab), TO-263AB
- HGT1S14N36G3VLS onsemi (ON), IGBT 390V 18A 100W TO263AB, Discrete Semiconductor Products~Transistors - IGBTs - Single
