MJ15004G Images
- Manufacturer: onsemi (ON)
- Category: Discrete Semiconductor Products~Transistors - Bipolar (BJT) - Single Package/Case: TO-204AA, TO-3
- Description: TRANS PNP 140V 20A TO3
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
MJ15004G Specifications:
- MfrPart.: MJ15004G
- Mfr: onsemi
- Description: TRANS PNP 140V 20A TO3
- Product Category: Discrete Semiconductor Products~Transistors - Bipolar (BJT) - Single
- Package: Tray
- Series: -
- PartStatus: Active
- TransistorType: PNP
- Current-Collector(Ic)(Max): 20 A
- Voltage-CollectorEmitterBreakdown(Max): 140 V
- VceSaturation(Max)@IbIc: 1V @ 500mA, 5A
- Current-CollectorCutoff(Max): 250µA
- DCCurrentGain(hFE)(Min)@IcVce: 25 @ 5A, 2V
- Power-Max: 250 W
- Frequency-Transition: 2MHz
- OperatingTemperature: -65°C ~ 200°C (TJ)
- MountingType: Through Hole
- Package/Case: TO-204AA, TO-3
- MJ15004G onsemi (ON), TRANS PNP 140V 20A TO3, Discrete Semiconductor Products~Transistors - Bipolar (BJT) - Single
