HGTD7N60C3S9A Images
- Manufacturer: onsemi (ON)
- Category: Discrete Semiconductor Products~Transistors - IGBTs - Single Package/Case: TO-252-3, DPak (2 Leads + Tab), SC-63
- Description: IGBT 600V 14A TO252AA
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
HGTD7N60C3S9A Specifications:
- MfrPart.: HGTD7N60C3S9A
- Mfr: onsemi
- Description: IGBT 600V 14A TO252AA
- Product Category: Discrete Semiconductor Products~Transistors - IGBTs - Single
- Package: Tape & Reel (TR),Cut Tape (CT)
- Series: -
- PartStatus: Last Time Buy
- IGBTType: -
- Voltage-CollectorEmitterBreakdown(Max): 600 V
- Current-Collector(Ic)(Max): 14 A
- Current-CollectorPulsed(Icm): 56 A
- Vce(on)(Max)@VgeIc: 2V @ 15V, 7A
- Power-Max: 60 W
- SwitchingEnergy: 165µJ (on), 600µJ (off)
- InputType: Standard
- GateCharge: 23 nC
- Td(on/off)@25°C: -
- TestCondition: -
- ReverseRecoveryTime(trr): -
- OperatingTemperature: -40°C ~ 150°C (TJ)
- MountingType: Surface Mount
- Package/Case: TO-252-3, DPak (2 Leads + Tab), SC-63
- HGTD7N60C3S9A onsemi (ON), IGBT 600V 14A TO252AA, Discrete Semiconductor Products~Transistors - IGBTs - Single
