FGH75T65SHDTLN4 Images
- Manufacturer: onsemi (ON)
- Category: Discrete Semiconductor Products~Transistors - IGBTs - Single Package/Case: TO-247-4
- Description: FS3 T TO247 75A 650V 4WL
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
FGH75T65SHDTLN4 Specifications:
- MfrPart.: FGH75T65SHDTLN4
- Mfr: onsemi
- Description: FS3 T TO247 75A 650V 4WL
- Product Category: Discrete Semiconductor Products~Transistors - IGBTs - Single
- Package: Tube
- Series: -
- PartStatus: Last Time Buy
- IGBTType: Trench Field Stop
- Voltage-CollectorEmitterBreakdown(Max): 650 V
- Current-Collector(Ic)(Max): 150 A
- Current-CollectorPulsed(Icm): 300 A
- Vce(on)(Max)@VgeIc: 2.1V @ 15V, 75A
- Power-Max: 455 W
- SwitchingEnergy: 1.06mJ (on), 1.56mJ (off)
- InputType: Standard
- GateCharge: 126 nC
- Td(on/off)@25°C: 55ns/189ns
- TestCondition: 400V, 75A, 15Ohm, 15V
- ReverseRecoveryTime(trr): 36 ns
- OperatingTemperature: -55°C ~ 175°C (TJ)
- MountingType: Through Hole
- Package/Case: TO-247-4
- FGH75T65SHDTLN4 onsemi (ON), FS3 T TO247 75A 650V 4WL, Discrete Semiconductor Products~Transistors - IGBTs - Single
