FGH75T65UPD-F085 Images
- Manufacturer: onsemi (ON)
- Category: Discrete Semiconductor Products~Transistors - IGBTs - Single Package/Case: TO-247-3
- Description: IGBT 650V 150A 375W TO-247AB
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
FGH75T65UPD-F085 Specifications:
- MfrPart.: FGH75T65UPD-F085
- Mfr: onsemi
- Description: IGBT 650V 150A 375W TO-247AB
- Product Category: Discrete Semiconductor Products~Transistors - IGBTs - Single
- Package: Tube
- Series: Automotive, AEC-Q101
- PartStatus: Not For New Designs
- IGBTType: Trench Field Stop
- Voltage-CollectorEmitterBreakdown(Max): 650 V
- Current-Collector(Ic)(Max): 150 A
- Current-CollectorPulsed(Icm): 225 A
- Vce(on)(Max)@VgeIc: 2.3V @ 15V, 75A
- Power-Max: 375 W
- SwitchingEnergy: 2.85mJ (on), 1.2mJ (off)
- InputType: Standard
- GateCharge: 578 nC
- Td(on/off)@25°C: 32ns/166ns
- TestCondition: 400V, 75A, 3Ohm, 15V
- ReverseRecoveryTime(trr): 85 ns
- OperatingTemperature: -55°C ~ 175°C (TJ)
- MountingType: Through Hole
- Package/Case: TO-247-3
- FGH75T65UPD-F085 onsemi (ON), IGBT 650V 150A 375W TO-247AB, Discrete Semiconductor Products~Transistors - IGBTs - Single
FGH75T65UPD-F085, onsemi authentic parts in stock from onsemi (ON) authorized distributors, order today, can ship immediately.
