FGH60T65SHD-F155 Images
- Manufacturer: onsemi (ON)
- Category: Discrete Semiconductor Products~Transistors - IGBTs - Single Package/Case: TO-247-3
- Description: IGBT TRENCH/FS 650V 120A TO247
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
FGH60T65SHD-F155 Specifications:
- MfrPart.: FGH60T65SHD-F155
- Mfr: onsemi
- Description: IGBT TRENCH/FS 650V 120A TO247
- Product Category: Discrete Semiconductor Products~Transistors - IGBTs - Single
- Package: Tube
- Series: -
- PartStatus: Active
- IGBTType: Trench Field Stop
- Voltage-CollectorEmitterBreakdown(Max): 650 V
- Current-Collector(Ic)(Max): 120 A
- Current-CollectorPulsed(Icm): 180 A
- Vce(on)(Max)@VgeIc: 2.1V @ 15V, 60A
- Power-Max: 349 W
- SwitchingEnergy: 1.69mJ (on), 630µJ (off)
- InputType: Standard
- GateCharge: 102 nC
- Td(on/off)@25°C: 26ns/87ns
- TestCondition: 400V, 60A, 6Ohm, 15V
- ReverseRecoveryTime(trr): 34.6 ns
- OperatingTemperature: -55°C ~ 175°C (TJ)
- MountingType: Through Hole
- Package/Case: TO-247-3
- FGH60T65SHD-F155 onsemi (ON), IGBT TRENCH/FS 650V 120A TO247, Discrete Semiconductor Products~Transistors - IGBTs - Single
