FGH30N60LSDTU Images
- Manufacturer: onsemi (ON)
- Category: Discrete Semiconductor Products~Transistors - IGBTs - Single Package/Case: TO-247-3
- Description: IGBT 600V 60A TO247-3
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
FGH30N60LSDTU Specifications:
- MfrPart.: FGH30N60LSDTU
- Mfr: onsemi
- Description: IGBT 600V 60A TO247-3
- Product Category: Discrete Semiconductor Products~Transistors - IGBTs - Single
- Package: Tube
- Series: -
- PartStatus: Active
- IGBTType: -
- Voltage-CollectorEmitterBreakdown(Max): 600 V
- Current-Collector(Ic)(Max): 60 A
- Current-CollectorPulsed(Icm): 90 A
- Vce(on)(Max)@VgeIc: 1.4V @ 15V, 30A
- Power-Max: 480 W
- SwitchingEnergy: 1.1mJ (on), 21mJ (off)
- InputType: Standard
- GateCharge: 225 nC
- Td(on/off)@25°C: 18ns/250ns
- TestCondition: 400V, 30A, 6.8Ohm, 15V
- ReverseRecoveryTime(trr): 35 ns
- OperatingTemperature: -55°C ~ 150°C (TJ)
- MountingType: Through Hole
- Package/Case: TO-247-3
- FGH30N60LSDTU onsemi (ON), IGBT 600V 60A TO247-3, Discrete Semiconductor Products~Transistors - IGBTs - Single
