FGH15T120SMD-F155 Images
- Manufacturer: onsemi (ON)
- Category: Discrete Semiconductor Products~Transistors - IGBTs - Single Package/Case: TO-247-3
- Description: IGBT 1200V 30A 333W TO247-3
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
FGH15T120SMD-F155 Specifications:
- MfrPart.: FGH15T120SMD-F155
- Mfr: onsemi
- Description: IGBT 1200V 30A 333W TO247-3
- Product Category: Discrete Semiconductor Products~Transistors - IGBTs - Single
- Package: Tube
- Series: -
- PartStatus: Active
- IGBTType: Trench Field Stop
- Voltage-CollectorEmitterBreakdown(Max): 1200 V
- Current-Collector(Ic)(Max): 30 A
- Current-CollectorPulsed(Icm): 60 A
- Vce(on)(Max)@VgeIc: 2.4V @ 15V, 15A
- Power-Max: 333 W
- SwitchingEnergy: 1.15mJ (on), 460µJ (off)
- InputType: Standard
- GateCharge: 128 nC
- Td(on/off)@25°C: 32ns/490ns
- TestCondition: 600V, 15A, 34Ohm, 15V
- ReverseRecoveryTime(trr): 72 ns
- OperatingTemperature: -55°C ~ 175°C (TJ)
- MountingType: Through Hole
- Package/Case: TO-247-3
- FGH15T120SMD-F155 onsemi (ON), IGBT 1200V 30A 333W TO247-3, Discrete Semiconductor Products~Transistors - IGBTs - Single
FGH15T120SMD-F155, onsemi authentic parts in stock from onsemi (ON) authorized distributors, order today, can ship immediately.
