FGH60N60SFDTU Images
- Manufacturer: onsemi (ON)
- Category: Discrete Semiconductor Products~Transistors - IGBTs - Single Package/Case: TO-247-3
- Description: IGBT FIELD STOP 600V 120A TO247
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
FGH60N60SFDTU Specifications:
- MfrPart.: FGH60N60SFDTU
- Mfr: onsemi
- Description: IGBT FIELD STOP 600V 120A TO247
- Product Category: Discrete Semiconductor Products~Transistors - IGBTs - Single
- Package: Tube
- Series: -
- PartStatus: Active
- IGBTType: Field Stop
- Voltage-CollectorEmitterBreakdown(Max): 600 V
- Current-Collector(Ic)(Max): 120 A
- Current-CollectorPulsed(Icm): 180 A
- Vce(on)(Max)@VgeIc: 2.9V @ 15V, 60A
- Power-Max: 378 W
- SwitchingEnergy: 1.79mJ (on), 670µJ (off)
- InputType: Standard
- GateCharge: 198 nC
- Td(on/off)@25°C: 22ns/134ns
- TestCondition: 400V, 60A, 5Ohm, 15V
- ReverseRecoveryTime(trr): 47 ns
- OperatingTemperature: -55°C ~ 150°C (TJ)
- MountingType: Through Hole
- Package/Case: TO-247-3
- FGH60N60SFDTU onsemi (ON), IGBT FIELD STOP 600V 120A TO247, Discrete Semiconductor Products~Transistors - IGBTs - Single
FGH60N60SFDTU, onsemi authentic parts in stock from onsemi (ON) authorized distributors, order today, can ship immediately.
