FGB40N60SM Images
- Manufacturer: onsemi (ON)
- Category: Discrete Semiconductor Products~Transistors - IGBTs - Single Package/Case: TO-263-3, D²Pak (2 Leads + Tab), TO-263AB
- Description: IGBT FIELD STOP 600V 80A D2PAK
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
FGB40N60SM Specifications:
- MfrPart.: FGB40N60SM
- Mfr: onsemi
- Description: IGBT FIELD STOP 600V 80A D2PAK
- Product Category: Discrete Semiconductor Products~Transistors - IGBTs - Single
- Package: Tape & Reel (TR),Cut Tape (CT)
- Series: -
- PartStatus: Obsolete
- IGBTType: Field Stop
- Voltage-CollectorEmitterBreakdown(Max): 600 V
- Current-Collector(Ic)(Max): 80 A
- Current-CollectorPulsed(Icm): 120 A
- Vce(on)(Max)@VgeIc: 2.3V @ 15V, 40A
- Power-Max: 349 W
- SwitchingEnergy: 870µJ (on), 260µJ (off)
- InputType: Standard
- GateCharge: 119 nC
- Td(on/off)@25°C: 12ns/92ns
- TestCondition: 400V, 40A, 6Ohm, 15V
- ReverseRecoveryTime(trr): -
- OperatingTemperature: -55°C ~ 175°C (TJ)
- MountingType: Surface Mount
- Package/Case: TO-263-3, D²Pak (2 Leads + Tab), TO-263AB
- FGB40N60SM onsemi (ON), IGBT FIELD STOP 600V 80A D2PAK, Discrete Semiconductor Products~Transistors - IGBTs - Single
