HGTG30N60B3 Images
- Manufacturer: onsemi (ON)
- Category: Discrete Semiconductor Products~Transistors - IGBTs - Single Package/Case: TO-247-3
- Description: IGBT 600V 60A 208W TO247
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
HGTG30N60B3 Specifications:
- MfrPart.: HGTG30N60B3
- Mfr: onsemi
- Description: IGBT 600V 60A 208W TO247
- Product Category: Discrete Semiconductor Products~Transistors - IGBTs - Single
- Package: Tube
- Series: -
- PartStatus: Obsolete
- IGBTType: -
- Voltage-CollectorEmitterBreakdown(Max): 600 V
- Current-Collector(Ic)(Max): 60 A
- Current-CollectorPulsed(Icm): 220 A
- Vce(on)(Max)@VgeIc: 1.9V @ 15V, 30A
- Power-Max: 208 W
- SwitchingEnergy: 500µJ (on), 680µJ (off)
- InputType: Standard
- GateCharge: 170 nC
- Td(on/off)@25°C: 36ns/137ns
- TestCondition: 480V, 30A, 3Ohm, 15V
- ReverseRecoveryTime(trr): -
- OperatingTemperature: -55°C ~ 150°C (TJ)
- MountingType: Through Hole
- Package/Case: TO-247-3
- HGTG30N60B3 onsemi (ON), IGBT 600V 60A 208W TO247, Discrete Semiconductor Products~Transistors - IGBTs - Single
HGTG30N60B3, onsemi authentic parts in stock from onsemi (ON) authorized distributors, order today, can ship immediately.
