FGA5065ADF Images
- Manufacturer: onsemi (ON)
- Category: Discrete Semiconductor Products~Transistors - IGBTs - Single Package/Case: TO-3P-3, SC-65-3
- Description: IGBT TRENCH/FS 650V 100A TO3PN
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
FGA5065ADF Specifications:
- MfrPart.: FGA5065ADF
- Mfr: onsemi
- Description: IGBT TRENCH/FS 650V 100A TO3PN
- Product Category: Discrete Semiconductor Products~Transistors - IGBTs - Single
- Package: Tube
- Series: -
- PartStatus: Active
- IGBTType: Trench Field Stop
- Voltage-CollectorEmitterBreakdown(Max): 650 V
- Current-Collector(Ic)(Max): 100 A
- Current-CollectorPulsed(Icm): 150 A
- Vce(on)(Max)@VgeIc: 2.2V @ 15V, 50A
- Power-Max: 268 W
- SwitchingEnergy: 1.35mJ (on), 309µJ (off)
- InputType: Standard
- GateCharge: 72.2 nC
- Td(on/off)@25°C: 20.8ns/62.4ns
- TestCondition: 400V, 50A, 6Ohm, 15V
- ReverseRecoveryTime(trr): 31.8 ns
- OperatingTemperature: -55°C ~ 175°C (TJ)
- MountingType: Through Hole
- Package/Case: TO-3P-3, SC-65-3
- FGA5065ADF onsemi (ON), IGBT TRENCH/FS 650V 100A TO3PN, Discrete Semiconductor Products~Transistors - IGBTs - Single
FGA5065ADF, onsemi authentic parts in stock from onsemi (ON) authorized distributors, order today, can ship immediately.
