MGSF1N02LT1G Images
- Manufacturer: onsemi (ON)
- Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single SupplierDevicePackage: SOT-23-3 (TO-236)
- Description: MOSFET N-CH 20V 750MA SOT23-3
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
MGSF1N02LT1G Specifications:
- MfrPart.: MGSF1N02LT1G
- Mfr: onsemi
- Description: MOSFET N-CH 20V 750MA SOT23-3
- Product Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
- Package: Tape & Reel (TR),Cut Tape (CT)
- Series: -
- PartStatus: Active
- FETType: N-Channel
- Technology: MOSFET (Metal Oxide)
- DraintoSourceVoltage(Vdss): 20 V
- Current-ContinuousDrain(Id)@25°C: 750mA (Ta)
- DriveVoltage(MaxRdsOnMinRdsOn): 4.5V, 10V
- RdsOn(Max)@IdVgs: 90mOhm @ 1.2A, 10V
- Vgs(th)(Max)@Id: 2.4V @ 250µA
- GateCharge(Qg)(Max)@Vgs: -
- Vgs(Max): ±20V
- InputCapacitance(Ciss)(Max)@Vds: 125 pF @ 5 V
- FETFeature: -
- PowerDissipation(Max): 400mW (Ta)
- OperatingTemperature: -55°C ~ 150°C (TJ)
- MountingType: Surface Mount
- SupplierDevicePackage: SOT-23-3 (TO-236)
- MGSF1N02LT1G onsemi (ON), MOSFET N-CH 20V 750MA SOT23-3, Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
MGSF1N02LT1G, onsemi authentic parts in stock from onsemi (ON) authorized distributors, order today, can ship immediately.
