FDMC6683PZ Images
- Manufacturer: onsemi (ON)
- Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single SupplierDevicePackage: 8-MLP (3.3x3.3)
- Description: MOSFET P-CH 20V 40A 8MLP
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
FDMC6683PZ Specifications:
- MfrPart.: FDMC6683PZ
- Mfr: onsemi
- Description: MOSFET P-CH 20V 40A 8MLP
- Product Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
- Package: Bulk
- Series: PowerTrench®
- PartStatus: Obsolete
- FETType: P-Channel
- Technology: MOSFET (Metal Oxide)
- DraintoSourceVoltage(Vdss): 20 V
- Current-ContinuousDrain(Id)@25°C: 40A (Tc)
- DriveVoltage(MaxRdsOnMinRdsOn): 2.5V, 4.5V
- RdsOn(Max)@IdVgs: -
- Vgs(th)(Max)@Id: 1.5V @ 250µA
- GateCharge(Qg)(Max)@Vgs: 74 nC @ 10 V
- Vgs(Max): ±12V
- InputCapacitance(Ciss)(Max)@Vds: 7995 pF @ 10 V
- FETFeature: -
- PowerDissipation(Max): 26W (Tc)
- OperatingTemperature: -55°C ~ 150°C (TJ)
- MountingType: Surface Mount
- SupplierDevicePackage: 8-MLP (3.3x3.3)
- FDMC6683PZ onsemi (ON), MOSFET P-CH 20V 40A 8MLP, Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
