ATP301-TL-H Images
- Manufacturer: onsemi (ON)
- Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single SupplierDevicePackage: ATPAK
- Description: MOSFET P-CH 100V 28A ATPAK
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
ATP301-TL-H Specifications:
- MfrPart.: ATP301-TL-H
- Mfr: onsemi
- Description: MOSFET P-CH 100V 28A ATPAK
- Product Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
- Package: Tape & Reel (TR),Cut Tape (CT)
- Series: -
- PartStatus: Obsolete
- FETType: P-Channel
- Technology: MOSFET (Metal Oxide)
- DraintoSourceVoltage(Vdss): 100 V
- Current-ContinuousDrain(Id)@25°C: 28A (Ta)
- DriveVoltage(MaxRdsOnMinRdsOn): 10V
- RdsOn(Max)@IdVgs: 75mOhm @ 14A, 10V
- Vgs(th)(Max)@Id: -
- GateCharge(Qg)(Max)@Vgs: 73 nC @ 10 V
- Vgs(Max): ±20V
- InputCapacitance(Ciss)(Max)@Vds: 4000 pF @ 20 V
- FETFeature: -
- PowerDissipation(Max): 70W (Tc)
- OperatingTemperature: 150°C (TJ)
- MountingType: Surface Mount
- SupplierDevicePackage: ATPAK
- ATP301-TL-H onsemi (ON), MOSFET P-CH 100V 28A ATPAK, Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
