FDC6561AN Images
- Manufacturer: onsemi (ON)
- Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Arrays Package/Case: SOT-23-6 Thin, TSOT-23-6
- Description: MOSFET 2N-CH 30V 2.5A SSOT6
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
FDC6561AN Specifications:
- MfrPart.: FDC6561AN
- Mfr: onsemi
- Description: MOSFET 2N-CH 30V 2.5A SSOT6
- Product Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Arrays
- Package: Tape & Reel (TR),Cut Tape (CT)
- Series: PowerTrench®
- PartStatus: Active
- FETType: 2 N-Channel (Dual)
- FETFeature: Logic Level Gate
- DraintoSourceVoltage(Vdss): 30V
- Current-ContinuousDrain(Id)@25°C: 2.5A
- RdsOn(Max)@IdVgs: 95mOhm @ 2.5A, 10V
- Vgs(th)(Max)@Id: 3V @ 250µA
- GateCharge(Qg)(Max)@Vgs: 3.2nC @ 5V
- InputCapacitance(Ciss)(Max)@Vds: 220pF @ 15V
- Power-Max: 700mW
- OperatingTemperature: -55°C ~ 150°C (TJ)
- MountingType: Surface Mount
- Package/Case: SOT-23-6 Thin, TSOT-23-6
- FDC6561AN onsemi (ON), MOSFET 2N-CH 30V 2.5A SSOT6, Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Arrays
FDC6561AN, onsemi authentic parts in stock from onsemi (ON) authorized distributors, order today, can ship immediately.
