HCPL2611V Images
- Manufacturer: onsemi (ON)
- Category: Isolators~Optoisolators - Logic Output Package/Case: 8-DIP (0.300, 7.62mm)
- Description: LOGIC IC OUTPUT OPTOCOUPLER
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
HCPL2611V Specifications:
- MfrPart.: HCPL2611V
- Mfr: Fairchild Semiconductor (Now part of ONsemi)
- Description: LOGIC IC OUTPUT OPTOCOUPLER
- Product Category: Isolators~Optoisolators - Logic Output
- Package: Tube
- Series: -
- PartStatus: Obsolete
- NumberofChannels: 1
- Inputs-Side1/Side2: 1/0
- Voltage-Isolation: 2500Vrms
- CommonModeTransientImmunity(Min): 10kV/µs
- InputType: DC
- OutputType: Open Collector
- Current-Output/Channel: 50 mA
- DataRate: 10Mbps
- PropagationDelaytpLH/tpHL(Max): 75ns, 75ns
- Rise/FallTime(Typ): 50ns, 12ns
- Voltage-Forward(Vf)(Typ): 1.4V
- Current-DCForward(If)(Max): 50mA
- Voltage-Supply: 4.5V ~ 5.5V
- OperatingTemperature: -40°C ~ 85°C
- MountingType: Through Hole
- Package/Case: 8-DIP (0.300, 7.62mm)
- HCPL2611V onsemi (ON), LOGIC IC OUTPUT OPTOCOUPLER, Isolators~Optoisolators - Logic Output
HCPL2611V, onsemi authentic parts in stock from onsemi (ON) authorized distributors, order today, can ship immediately.
